LUXTAR® Ledramp X12 Black Edition 120W <36cm>

Luxtar® X12 Black Edition has a light intensity of 6013 lumens and is 36 cm long. The brightness can be compared to 6 original halogen 55w | 1000 Lumen (+-200 lm).

Product information
Size mm 362x63x85
LED Chips Power W 120
Actual Power Consumption 87,6
Moisture protection value (IPXX) IP68
Light image Driving, Spot
Volt (V) Multi-voltage, 9, 12, 14, 18, 24, 28, 32
Power consumption 3.6A @24V, 6.4A @13.7V
Lamp cap / Contact HB4 , 9006
Authorisation CE, EMC, RoHS
Brand:

Information about the programme

Luxtar® X12 Ledramp Black Edition

The Luxtar X Series is designed with side-mounted diode lamps that are not only unique but also improve performance. The Black Edition offers discreet looks while delivering top performance for better visibility. Luxtar X12 Black Edition is ideal for those who want the best of both worlds: style and performance. Theoretical values of LED ramp 120 W & 7 392 lumens Luxtar Led ramp X 12 has a theoretical value of 120 W and 7,392 lumens. When comparing other options on the market, you should keep these factors in mind. Actual Values of LED Ramp 87.6 W & 6 013 lumens If you compare the actual output value of 87.6 watts & 6,012 lumens, it can be compared with almost 6 halogen lamps that with 55W have a light value of about 1,000 lumens (+-200lm). Size 36cm volts 10-32 Areas of use Passenger car | Commercial vehicle | Van | Lorry | Pickup truck Choice of reflector / light pattern on LED Ramp Spot & Driving Spot: Optimised for maximum range, narrow beam pattern. Suitable for those who prioritise range of light or at higher speeds where the focus is naturally on longer distances. Driving: Optimised for wide light pattern with reduced range. Also called distant light image. Suitable for those looking for a wide light for better side visibility.
